San Ace 40 9GA Type Low Power Consumption Fans

Sanyo Denki San Ace 40 9GA Type Low Power Consumption Fans combine large airflow and low noise with reduced power consumption. This series of fans cuts power consumption by approximately 50% and reduces the sound pressure level by approximately 4dB(A) compared to the conventional product model. These fans provide improved cooling performance and feature a bipolar driving method to improve efficiency and reduce losses within circuits. Sanyo Denki San Ace 40 9GA fans are ideal for 1U servers, storage, telecom equipment, and power supplies.

Rezultāti: 98
Atlasīt Attēls Detaļas Nr.
 Raž.
Apraksts Datu lapa Pieejamība Cenas noteikšana (EUR) Atlasiet rezultātus tabulā pēc vienības cenas, pamatojoties uz daudzumu.
Daudz. RoHS ECAD modelis Tips
Augstums
Dziļums
Platums
Darba barošanas spriegums
Gaisa plūsma
Ātrums
Gultņu tips
Troksnis
Jaudas kategorija
Funkcijas:
Korpusa materiāls
Izvada veids
Sērija
Sanyo Denki DC ventilatori DC Axial Fan, 40x40x15mm, 12VDC, High Performance, Low Power, Tachometer, PWM
Datu lapa
Komentāri par produktiem
840Ir noliktavā
Min.: 1
Vair.: 1

Axial 40 mm 15 mm 40 mm 12 VDC 12.7 CFM (0.36 m3/min) 13100 RPM Ball 42 dBA 2.04 W Tachometer, PWM Plastic Wire Leads - 4 9GA Type
Sanyo Denki DC ventilatori DC Axial Fan, 40x40x20mm, 5VDC, High Performance, Low Power, Tachometer, PWM
Datu lapa
233Ir noliktavā
Min.: 1
Vair.: 1

Axial 40 mm 20 mm 40 mm 5 VDC 7.4 CFM (0.21 m3/min) 8000 RPM Ball 28 dBA 900 mW Tachometer, PWM Plastic Wire Leads - 4 9GA Type
Sanyo Denki DC ventilatori DC Axial Fan, 40x40x28mm, 12VDC, High Performance, Low Power, Tachometer, PWM
Datu lapa
124Ir noliktavā
Min.: 1
Vair.: 1

Axial 40 mm 28 mm 40 mm 12 VDC 21.5 CFM (0.61 m3/min) 16500 RPM Ball 53 dBA 4.68 W Tachometer, PWM Plastic Wire Leads - 4 9GA Type
Sanyo Denki DC ventilatori Axial Fan, 40x40x28mm, 12VDC, High Performance, Low Power, Ribless, Tach/PWM
Datu lapa
120Ir noliktavā
Min.: 1
Vair.: 1

Axial 40 mm 28 mm 40 mm 12 VDC 21.5 CFM (0.61 m3/min) 16500 RPM Ball 53 dBA 4.68 W Tachometer, PWM Plastic Wire Leads - 4 9GA Type
Sanyo Denki DC ventilatori Axial Fan, 40x40x28mm, 12VDC, High Performance, Low Power, Ribless, Tach/PWM
Datu lapa
192Ir noliktavā
Min.: 1
Vair.: 1

Axial 40 mm 28 mm 40 mm 12 VDC 19.1 CFM (0.54 m3/min) 14500 RPM Ball 50 dBA 3.36 W Tachometer, PWM Plastic Wire Leads - 4 9GA Type
Sanyo Denki DC ventilatori DC Axial Fan, 40x40x28mm, 12VDC, High Performance, Low Power, Tachometer, PWM
Datu lapa
532Ir noliktavā
Min.: 1
Vair.: 1

Axial 40 mm 28 mm 40 mm 12 VDC 23.7 CFM (0.67 m3/min) 18000 RPM Ball 54 dBA 5.88 W Tachometer, PWM Plastic Wire Leads - 4 9GA Type
Sanyo Denki DC ventilatori Axial Fan, 40x40x28mm, 12VDC, High Performance, Low Power, Ribless, Tach/PWM
Datu lapa
164Ir noliktavā
Min.: 1
Vair.: 1

Axial 40 mm 28 mm 40 mm 12 VDC 23.7 CFM (0.67 m3/min) 18000 RPM Ball 54 dBA 5.88 W Tachometer, PWM Plastic Wire Leads - 4 9GA Type
Sanyo Denki DC ventilatori DC Axial Fan, 40x40x28mm, 12VDC, High Performance, Low Power, Tachometer, PWM
Datu lapa
257Ir noliktavā
Min.: 1
Vair.: 1

Axial 40 mm 28 mm 40 mm 12 VDC 28.6 CFM (0.81 m3/min) 22000 RPM Ball 61 dBA 11.04 W Tachometer, PWM Plastic Wire Leads - 4 9GA Type
Sanyo Denki DC ventilatori DC Axial Fan, 40x40x28mm, 12VDC, High Performance, Low Power, Tachometer, PWM
Datu lapa
562Ir noliktavā
Min.: 1
Vair.: 1

Axial 40 mm 28 mm 40 mm 12 VDC 16.2 CFM (0.46 m3/min) 12500 RPM Ball 47 dBA 2.52 W Tachometer, PWM Plastic Wire Leads - 4 9GA Type
Sanyo Denki DC ventilatori DC Axial Fan, 40x40x28mm, 24VDC, High Performance, Low Power, Tachometer, PWM
Datu lapa
650Ir noliktavā
Min.: 1
Vair.: 1

Axial 40 mm 28 mm 40 mm 24 VDC 21.5 CFM (0.61 m3/min) 16500 RPM Ball 53 dBA 5.28 W Tachometer, PWM Plastic Wire Leads - 4 9GA Type
Sanyo Denki DC ventilatori DC Axial Fan, 40x40x28mm, 24VDC, High Performance, Low Power, Tachometer, PWM
Datu lapa
112Ir noliktavā
Min.: 1
Vair.: 1

Axial 40 mm 28 mm 40 mm 24 VDC 19.1 CFM (0.54 m3/min) 14500 RPM Ball 50 dBA 3.84 W Tachometer, PWM Plastic Wire Leads - 4 9GA Type
Sanyo Denki DC ventilatori Axial Fan, 40x40x28mm, 24VDC, High Performance, Low Power, Ribless, Tach/PWM
Datu lapa
124Ir noliktavā
Min.: 1
Vair.: 1

Axial 40 mm 28 mm 40 mm 24 VDC 19.1 CFM (0.54 m3/min) 14500 RPM Ball 50 dBA 3.84 W Tachometer, PWM Plastic Wire Leads - 4 9GA Type
Sanyo Denki DC ventilatori DC Axial Fan, 40x40x28mm, 24VDC, High Performance, Low Power, Tachometer, PWM
Datu lapa
202Ir noliktavā
Min.: 1
Vair.: 1

Axial 40 mm 28 mm 40 mm 24 VDC 16.2 CFM (0.46 m3/min) 12500 RPM Ball 47 dBA 2.64 W Tachometer, PWM Plastic Wire Leads - 4 9GA Type
Sanyo Denki DC ventilatori DC Axial Fan, 40x40x15mm, 12VDC, High Performance, Low Power, Tachometer
Datu lapa
Komentāri par produktiem
104Ir noliktavā
360Pēc pasūtījuma
Min.: 1
Vair.: 1

Axial 40 mm 15 mm 40 mm 12 VDC 12.7 CFM (0.36 m3/min) 13100 RPM Ball 42 dBA 2.04 W Tachometer Plastic Wire Leads - 3 9GA Type
Sanyo Denki DC ventilatori DC Axial Fan, 40x40x28mm, 12VDC, High Performance, Low Power, Tachometer, PWM
Datu lapa
45Ir noliktavā
126Paredzamais 08.06.2026
Min.: 1
Vair.: 1

Axial 40 mm 28 mm 40 mm 12 VDC 19.1 CFM (0.54 m3/min) 14500 RPM Ball 50 dBA 3.36 W Tachometer, PWM Plastic Wire Leads - 4 9GA Type

Sanyo Denki DC ventilatori DC Axial Fan, 40x40x28mm, 24VDC, High Performance, Low Power, Tachometer
Datu lapa
Komentāri par produktiem
55Ir noliktavā
Min.: 1
Vair.: 1

Axial 40 mm 28 mm 40 mm 24 VDC 16.2 CFM (0.46 m3/min) 12500 RPM Ball 47 dBA 2.64 W Tachometer Plastic Wire Leads - 3 9GA Type
Sanyo Denki DC ventilatori DC Axial Fan, 40x40x28mm, 24VDC, High Performance, Low Power, Tachometer, PWM
Datu lapa
59Ir noliktavā
378Paredzamais 26.05.2026
Min.: 1
Vair.: 1

Axial 40 mm 28 mm 40 mm 24 VDC 23.7 CFM (0.67 m3/min) 18000 RPM Ball 54 dBA 6.48 W Tachometer, PWM Plastic Wire Leads - 4 9GA Type
Sanyo Denki DC ventilatori Axial Fan, 40x40x28mm, 24VDC, High Performance, Low Power, Ribless, Tach/PWM
Datu lapa
61Ir noliktavā
126Paredzamais 04.05.2026
Min.: 1
Vair.: 1

Axial 40 mm 28 mm 40 mm 24 VDC 23.7 CFM (0.67 m3/min) 18000 RPM Ball 54 dBA 6.48 W Tachometer, PWM Plastic Wire Leads - 4 9GA Type
Sanyo Denki DC ventilatori DC Axial Fan, 40x40x20mm, 12VDC, High Performance, Low Power, Tachometer, PWM
Datu lapa
1 470Paredzamais 22.06.2026
Min.: 1
Vair.: 1

Axial 40 mm 20 mm 40 mm 12 VDC 14.8 CFM (0.42 m3/min) 16000 RPM Ball 47 dBA 2.76 W Tachometer, PWM Plastic Wire Leads - 4 9GA Type
Sanyo Denki DC ventilatori DC Axial Fan, 40x40x20mm, 5VDC, High Performance, Low Power, Tachometer, PWM
Datu lapa
140Pēc pasūtījuma
Min.: 1
Vair.: 1

Axial 40 mm 20 mm 40 mm 5 VDC 11.7 CFM (0.33 m3/min) 12400 RPM Ball 40 dBA 1.75 W Tachometer, PWM Plastic Wire Leads - 4 9GA Type
Sanyo Denki DC ventilatori DC Axial Fan, 40x40x15mm, 12VDC, High Performance, Low Power, Tachometer
Datu lapa
360Pēc pasūtījuma
Min.: 1
Vair.: 1

Axial 40 mm 15 mm 40 mm 12 VDC 7.1 CFM (0.2 m3/min) 7300 RPM Ball 28 dBA 720 mW Tachometer Plastic Wire Leads - 3 9GA Type
Sanyo Denki DC ventilatori DC Axial Fan, 40x40x28mm, 12VDC, High Performance, Low Power, Tachometer
Datu lapa
Komentāri par produktiem
126Paredzamais 13.04.2026
Min.: 1
Vair.: 1

Axial 40 mm 28 mm 40 mm 12 VDC Tachometer 9GA Type
Sanyo Denki DC ventilatori DC Axial Fan, 40x40x20mm, 12VDC, High Performance, Low Power, Tachometer, PWM
Datu lapa
700Pēc pasūtījuma
Min.: 1
Vair.: 1

Axial 40 mm 20 mm 40 mm 12 VDC 11.7 CFM (0.33 m3/min) 12400 RPM Ball 40 dBA 1.68 W Tachometer, PWM Plastic Wire Leads - 4 9GA Type
Sanyo Denki DC ventilatori DC Axial Fan, 40x40x20mm, 24VDC, High Performance, Low Power, Tachometer, PWM
Datu lapa
350Pēc pasūtījuma
Min.: 1
Vair.: 1

Axial 40 mm 20 mm 40 mm 24 VDC 7.42 CFM (0.21 m3/min) 8000 RPM Ball 28 dBA 960 mW Tachometer, PWM Plastic Wire Leads - 4 9GA Type
Sanyo Denki DC ventilatori DC Axial Fan, 40x40x20mm, 24VDC, High Performance, Low Power, Tachometer, PWM
Datu lapa
708Pēc pasūtījuma
Min.: 1
Vair.: 1

Axial 40 mm 20 mm 40 mm 24 VDC 14.8 CFM (0.42 m3/min) 16000 RPM Ball 47 dBA 3.12 W Tachometer, PWM Plastic Wire Leads - 4 9GA Type
