AMPMODU 2mm Connector System Headers & Receptacles

TE Connectivity's (TE) AMPMODU 2mm Connectors System Headers and Receptacles offer a maximum 2A current rating, 125VAC operating voltage rating, and 3 to 20 positions. These breakaway headers and board-to-board receptacles occupy 38% less space than traditional 2.54mm centerline products. AMPMODU connectors are designed for use across multiple industry segments where space constraints are of particular concern. TE AMPMODU 2mm Connectors System Headers and Receptacles are ideal for programmable logic controllers (PLC), servo drives, industrial controls, and material handling applications.

Rezultāti: 341
Atlasīt Attēls Detaļas Nr.
 Raž.
Apraksts Datu lapa Pieejamība Cenas noteikšana (EUR) Atlasiet rezultātus tabulā pēc vienības cenas, pamatojoties uz daudzumu.
Daudz. RoHS ECAD modelis Produkts
Pozīciju skaits
Solis
Rindu skaits
Izvada veids
Montāžas leņķis
Strāvas parametri
Sprieguma kategorija
Minimālā darba temperatūra
Maksimālā darba temperatūra
Kontakta pārklājums
Kontakta materiāls
Korpusa materiāls
Sērija
Iepakojums


TE Connectivity Board to Board un mezanīna savienotāji 10P,2MM,B-B,REC,SRVT 2.7,0.1AU,TB
Datu lapa
1 764Ir noliktavā
Min.: 1
Vair.: 1

Receptacles 10 Position 2 mm (0.079 in) 1 Row Solder Vertical 2 A 125 VAC - 40 C + 125 C Gold Phosphor Bronze Liquid Crystal Polymer (LCP) AMPMODU 2 mm Tube


TE Connectivity Board to Board un mezanīna savienotāji 12P,2MM,BB,REC,DRVT SMD,AU.76,TB,W/CP
Datu lapa
2 587Ir noliktavā
Min.: 1
Vair.: 1

Receptacles 12 Position 2 mm (0.079 in) 2 Row Solder Vertical 2 A 125 VAC - 40 C + 125 C Gold Phosphor Bronze Liquid Crystal Polymer (LCP) AMPMODU 2 mm Tube
TE Connectivity Board to Board un mezanīna savienotāji 8P,2MM,B-B,RE,DRVT, SMD,0.1AU,TB,W/CP
Datu lapa
3 860Ir noliktavā
Min.: 1
Vair.: 1

Receptacles 8 Position 2 mm (0.079 in) 2 Row Solder Vertical 2 A 125 VAC - 40 C + 125 C Gold Phosphor Bronze Liquid Crystal Polymer (LCP) AMPMODU 2 mm Tube
TE Connectivity Board to Board un mezanīna savienotāji 2P,2MM,BB,REC,SRVT, 2.0,0.76AU,TUBE WCAP
Datu lapa
3 115Ir noliktavā
Min.: 1
Vair.: 1
Rullis: 110

Receptacles 2 Position 2 mm (0.079 in) 1 Row Solder Vertical 2 A 125 VAC - 40 C + 125 C Gold Phosphor Bronze Liquid Crystal Polymer (LCP) Reel, Cut Tape


TE Connectivity Board to Board un mezanīna savienotāji 10P,2MM,B-B,REC,DRVT 2.7,0.76AU,TB
Datu lapa
2 420Ir noliktavā
Min.: 1
Vair.: 1

Receptacles 10 Position 2 mm (0.079 in) 2 Row Solder Vertical 2 A 125 VAC - 40 C + 125 C Gold Phosphor Bronze Liquid Crystal Polymer (LCP) AMPMODU 2 mm Tube
TE Connectivity Board to Board un mezanīna savienotāji 4P,2MM,B-B,REC,SRVT, 2.7,0.76AU,TB
Datu lapa
3 778Ir noliktavā
Min.: 1
Vair.: 1

Receptacles 4 Position 2 mm (0.079 in) 1 Row Solder Vertical 2 A 125 VAC - 40 C + 125 C Gold Phosphor Bronze Liquid Crystal Polymer (LCP) AMPMODU 2 mm Tube
TE Connectivity Board to Board un mezanīna savienotāji 12P,2MM,B-B,REC,DRVT 2.7,0.76AU,TB
Datu lapa
1 739Ir noliktavā
Min.: 1
Vair.: 1

Receptacles 12 Position 2 mm (0.079 in) 2 Row Solder Vertical 2 A 125 VAC - 40 C + 125 C Gold Phosphor Bronze Liquid Crystal Polymer (LCP) AMPMODU 2 mm Tube
TE Connectivity Board to Board un mezanīna savienotāji 6P,2MM,BB,REC,SRVT, SMD,0.1AU,TR,W/CP
Datu lapa
4 317Ir noliktavā
Min.: 1
Vair.: 1
Rullis: 900

Receptacles 6 Position 2 mm (0.079 in) 1 Row Solder Vertical 2 A 125 VAC - 40 C + 125 C Gold Phosphor Bronze Liquid Crystal Polymer (LCP) AMPMODU 2 mm Reel, Cut Tape
TE Connectivity Board to Board un mezanīna savienotāji 8P,2MM,B-B,REC,DRVT, 2.7,0.1AU,TB
Datu lapa
3 227Ir noliktavā
Min.: 1
Vair.: 1

Receptacles 8 Position 2 mm (0.079 in) 2 Row Solder Vertical 2 A 125 VAC - 40 C + 125 C Gold Phosphor Bronze Liquid Crystal Polymer (LCP) AMPMODU 2 mm Tube
TE Connectivity Board to Board un mezanīna savienotāji 14P,2MM,B-B,REC, DRVT,SMD,SN,TR,W/CP
Datu lapa
2 070Ir noliktavā
Min.: 1
Vair.: 1
Rullis: 700

Receptacles 14 Position 2 mm (0.079 in) 2 Row Solder Vertical 2 A 125 VAC - 40 C + 105 C Tin Phosphor Bronze Liquid Crystal Polymer (LCP) Reel, Cut Tape
TE Connectivity Board to Board un mezanīna savienotāji 2P,2MM,B-B,REC,SRHZ,SMD,0.1AU
Datu lapa
5 839Ir noliktavā
Min.: 1
Vair.: 1
Rullis: 2 000

Receptacles 2 Position 2 mm (0.079 in) 1 Row Solder Horizontal 2 A 125 VAC - 40 C + 125 C Gold Phosphor Bronze Liquid Crystal Polymer (LCP) Reel, Cut Tape


TE Connectivity Board to Board un mezanīna savienotāji 5P,2MM,BB,REC,SRVT,SMD,AU.76,TR,W/CP
Datu lapa
3 808Ir noliktavā
MouseReel ir pieejams
Min.: 1
Vair.: 1
Rullis: 900

Receptacles 5 Position 2 mm (0.079 in) 1 Row Solder Vertical 2 A 125 VAC - 40 C + 125 C Gold Phosphor Bronze Liquid Crystal Polymer (LCP) AMPMODU 2 mm Reel, Cut Tape, MouseReel
TE Connectivity Board to Board un mezanīna savienotāji 14P,2MM,BB,REC,DRVT SMD,0.1AU,TR,W/CP
Datu lapa
1 960Ir noliktavā
Min.: 1
Vair.: 1
Rullis: 700

Receptacles 14 Position 2 mm (0.079 in) 2 Row Solder Vertical 2 A 125 VAC - 40 C + 125 C Gold Phosphor Bronze Liquid Crystal Polymer (LCP) Reel, Cut Tape
TE Connectivity Board to Board un mezanīna savienotāji 6P,2MM,B-B,REC,SRHZ, 2.8,0.1AU,TB
Datu lapa
4 254Ir noliktavā
Min.: 1
Vair.: 1
Rullis: 500

Receptacles 6 Position 2 mm (0.079 in) 1 Row Solder Horizontal 2 A 125 VAC - 40 C + 125 C Gold Phosphor Bronze Liquid Crystal Polymer (LCP) AMPMODU 2 mm Reel, Cut Tape


TE Connectivity Board to Board un mezanīna savienotāji 5P,2MM,B-B,REC,SRHZ,2.8,0.76AU,TR
Datu lapa
2 428Ir noliktavā
Min.: 1
Vair.: 1
Rullis: 500

Receptacles 5 Position 2 mm (0.079 in) 1 Row Solder Right Angle 2 A - 40 C + 125 C Gold Phosphor Bronze Liquid Crystal Polymer (LCP) AMPMODU 2 mm Reel, Cut Tape


TE Connectivity Board to Board un mezanīna savienotāji 20P,2MM,B-B,REC,DRHZ 2.8,0.76AU,TB
Datu lapa
618Ir noliktavā
Min.: 1
Vair.: 1
Rullis: 400

Receptacles 20 Position 2 mm (0.079 in) 2 Row Solder Horizontal 2 A 125 VAC - 40 C + 125 C Gold Phosphor Bronze Liquid Crystal Polymer (LCP) AMPMODU 2 mm Reel, Cut Tape


TE Connectivity Board to Board un mezanīna savienotāji 6P,2MM,BB,REC,SRVT, SMD,AU.76,TR,W/CP
Datu lapa
2 144Ir noliktavā
Min.: 1
Vair.: 1
Rullis: 900

Receptacles 6 Position 2 mm (0.079 in) 1 Row Solder Vertical 2 A 125 VAC - 40 C + 125 C Gold Phosphor Bronze Liquid Crystal Polymer (LCP) AMPMODU 2 mm Reel, Cut Tape
TE Connectivity Board to Board un mezanīna savienotāji 6P,2MM,B-B,REC,DRHZ, 2.8,0.76AU,TB
Datu lapa
2 640Ir noliktavā
Min.: 1
Vair.: 1
Rullis: 400

Receptacles 6 Position 2 mm (0.079 in) 2 Row Solder Vertical 2 A 125 VAC - 40 C + 125 C Gold Phosphor Bronze Liquid Crystal Polymer (LCP) AMPMODU 2 mm Reel, Cut Tape
TE Connectivity Board to Board un mezanīna savienotāji 10P,2MM,B-B,RE,DRVT, SMD,0.1AU,TB,W/CP
Datu lapa
27Ir noliktavā
Min.: 1
Vair.: 1

Receptacles 10 Position 2 mm (0.079 in) 2 Row Solder Vertical 2 A 125 VAC - 40 C + 125 C Gold Phosphor Bronze Liquid Crystal Polymer (LCP) AMPMODU 2 mm Tube
TE Connectivity Board to Board un mezanīna savienotāji 14P,2MM,B-B,RE,DRVT, SMD,0.1AU,TB,W/CP
Datu lapa
581Ir noliktavā
Min.: 1
Vair.: 1

Receptacles 14 Position 2 mm (0.079 in) 2 Row Solder Vertical 2 A 125 VAC - 40 C + 125 C Gold Phosphor Bronze Liquid Crystal Polymer (LCP) AMPMODU 2 mm Tube


TE Connectivity Board to Board un mezanīna savienotāji 10P,2MM,B-B,REC,SRHZ 2.8,0.76AU,TB
Datu lapa
870Ir noliktavā
Min.: 1
Vair.: 1
Rullis: 500

Receptacles 10 Position 2 mm (0.079 in) 1 Row Solder Horizontal 2 A 125 VAC - 40 C + 125 C Gold Phosphor Bronze Liquid Crystal Polymer (LCP) AMPMODU 2 mm Reel, Cut Tape
TE Connectivity Board to Board un mezanīna savienotāji 4P,2MM,BB,REC,SRVT, SMD,AU.76,TR,W/CP
Datu lapa
3 861Ir noliktavā
Min.: 1
Vair.: 1
Rullis: 900

Receptacles 4 Position 2 mm (0.079 in) 1 Row Solder Vertical 2 A 125 VAC - 40 C + 125 C Gold Phosphor Bronze Liquid Crystal Polymer (LCP) AMPMODU 2 mm Reel, Cut Tape

TE Connectivity Board to Board un mezanīna savienotāji 6P,2MM,B-B,REC,DRVT, 2.7,0.76AU,TB
Datu lapa
4 026Ir noliktavā
Min.: 1
Vair.: 1

Receptacles 6 Position 2 mm (0.079 in) 2 Row Solder Vertical 2 A 125 VAC - 40 C + 125 C Gold Phosphor Bronze Liquid Crystal Polymer (LCP) AMPMODU 2 mm Tube


TE Connectivity Board to Board un mezanīna savienotāji 20P,2MM,BB,REC,DRVT SMD,AU.76,TB,W/CP
Datu lapa
580Ir noliktavā
Min.: 1
Vair.: 1

Receptacles 20 Position 2 mm (0.079 in) 2 Row Solder Vertical 2 A 125 VAC - 40 C + 125 C Gold Phosphor Bronze Liquid Crystal Polymer (LCP) AMPMODU 2 mm Tube


TE Connectivity Board to Board un mezanīna savienotāji 20P,2MM,B-B,REC,DRHZ 2.8,0.1AU,TB
Datu lapa
1 986Ir noliktavā
Min.: 1
Vair.: 1
Rullis: 400

Receptacles 20 Position 2 mm (0.079 in) 2 Row Solder Horizontal 2 A 125 VAC - 40 C + 125 C Gold Phosphor Bronze Liquid Crystal Polymer (LCP) AMPMODU 2 mm Reel, Cut Tape
